TFT Controller Board, EDP to HDMI/ VGA/ DVI

Model: TBJ156HD-01

Function: TFT LCD Controller
Interface:  EDP to HDMI/VGA/DVI
Key: 5key
PCB (W x H) (mm): 123.2×82.5
Download Resources: Specification | 2D Rendering

$13.00$21.00



TBJ156HD-01 LCD Scaler Board | Convert EDP 30-pin to HDMI, VGA, DVI |
Support LCD resolution (max.): 1920×1080, typical screen size: 11.6″/ 13.3″/ 15.6″ |
Support button operation, multi-function on Screen Display (OSD) operation, and optional remote control function |
The TFT control board can be compatible with our 15.6-inch TFT LCD TTX156XHT-01.
The material is RoHS compliant.



Function TFT LCD Controller
Supply Voltage (V) 12 Typ
Interface EDP to HDMI/VGA/DVI
LCM SIZE(inch) 11.6/13.3/15.6
LCM Resolution supported (pixel) 1920×1080
PCB (W x H ) (mm) 123.2×82.5
Direct Current (without LCM ) (mA) 510 Typ
LCM connector 30PIN-0.5S
VGA connector VGA15 (Female )
HDMI connector HDMI-019S
Key connector 14PIN-2.0S
DVI connector DVI-I (Female )
Operational Temperature (°C) -10 ~ +60
Storage Temperature (°C) -20 ~ +70



Manufacturer ISO Certification

ISO certification Tailor Pixels











Quality Verification Processes



2 Types of Microscopy-Inspections
  • In process of Backlight assembly and FOG bounding
3 Stages of Aging-Tests
  • Sampling from FOG line, testing in normal and high-temperature environment
  • Sampling from Finished Product: testing in high-temperature enviroment
4 Types of Lab Tests
  • High-Temperature High-Humidity Resistance Test
  • Thermal Shock Test
  • Vibration Test
  • Drop test
5 Times of Quality Inspections
  • Materials in-coming inspection
  • Online inspection
  • Final inspection before packing
  • IQC inspection before stock
  • OQC inspection before loading
