4.3 inch TFT Controller Board, RGB to VGA/CVBS

Model: TBJ043VG-01

Function:  TFT LCD Controller
Interface: RGB to VGA/CVBS
Key: 5key
PCB (W x H) (mm): 90.6×54.0
Download Resources: Specification | 2D Rendering

$7.00$13.00



TBJ043VG-01 LCD Scaler Board | Convert RGB 40-pin to VGA, CVBS |
Support LCD resolution (max.):480X272, typical screen size: 4.3″/ 5.0″ |
Support button operation, multi-function OSD operation, and optional remote control function |
The TFT control board can be compatible with our 4.3-inch TFT module TTX043HHS-02, 5.0-inch TFT module TTX050BHS-01, and original AT043TN24 V.1, AT043TN25 V.2, TM050RDH03.
The material is RoHS compliant.



Function TFT LCD Controller
Supply Voltage (V) 12 Typ
Interface RGB to VGA/CVBS
LCM SIZE(inch) 4.3
LCM Resolution supported (pixel) 480X272
PCB (W x H ) (mm)  90.6×54.0
Direct Current (without LCM ) (mA) 100 Typ
LCM connector 40PIN-0.5S
VGA connector 12PIN-2.0S
AV connector 6PIN-2.0S
Key connector 8PIN-2.0S
Operational Temperature (°C) -10 ~ +60
Storage Temperature (°C) -20 ~ +70



Manufacturer ISO Certification

ISO certification Tailor Pixels











Quality Verification Processes



2 Types of Microscopy-Inspections
  • In process of Backlight assembly and FOG bounding
3 Stages of Aging-Tests
  • Sampling from FOG line, testing in normal and high-temperature environment
  • Sampling from Finished Product: testing in high-temperature enviroment
4 Types of Lab Tests
  • High-Temperature High-Humidity Resistance Test
  • Thermal Shock Test
  • Vibration Test
  • Drop test
5 Times of Quality Inspections
  • Materials in-coming inspection
  • Online inspection
  • Final inspection before packing
  • IQC inspection before stock
  • OQC inspection before loading
