TTH348BVT-01CG| 3.48- inch Touch Display | 172×640 | SPI, QSPI, MIPI, MCU, RGB | In-Cell Capacitive Touch
The bar touch display has unique features:
– Ratio of about 3.5, suitable for applications with long interface design
– In-cell capacitive touch, which can provide the touch function without additional touchscreen
– Customize the cover glass to match the appearance of your terminal.
– This Liquid Crystal Display has a built-in AXS15231B controller.
The material is RoHS-compliant.
| Diagonal (inch) | 3.48″ |
| Resolution (pixel) | 172×640 |
| Display Type | IPS |
| Display Mode | Transmissive |
| Optimal View | Full View |
| Touch Screen | In-Cell Capacitive Touch with CG |
| Module Dimensions (mm) (W x H x D) | 28.989×92.692 x3.035 |
| Active Area (mm) (W x H) | 22.575×84.0 |
| Luminance (cd/m2) | 350 |
| Interface | SPI/QSPI/MIPI/MCU/RGB |
| Driver IC | AXS15231B |
| Operational Temperature (°C) | -20 ~ +70 |
| Storage Temperature (°C) | -30 ~ +80 |
