10.1 inch Touch Display, 1280×800, HDMI Interface

Model: TBD-T101QHH-01C

Diagonal: 10.1″
Resolution: 1280×800 Pixels
Display Type: IPS
Touch Screen: Capacitive Touch
Interface: LVDS to HDMI
Driver IC: HX8288*4&HX8695*1

Download Resources: Specification |Catalog



TBD-T101QHH-01C | 10.1″ IPS TFT LCD with CTP | 1280×800 Pixels | LVDS to HDMI | USB Touch
The 10.1″ touch display goes with a HDMI adapter for display and USB adapter for touch, easy drive, and instant use.
This touch display has an enhanced version for the application with strict waterproof requirements.

The material is RoHS-compliant.


Diagonal (inch) 10.1
Resolution (pixel) 1280×800
Display Type IPS
Display Mode Transmissive
Optimal View Full View
Touch Screen Capacitive Touch Screen
Module Dimensions (mm) (W x H x D) 229.52×149.12×2.66
Active Area (mm) (W x H) 216.96×135.6
Luminance (cd/m2) 350
Interface HDMI
Driver IC HX8288*4&HX8695*1
Operational Temperature (°C) -20 ~ +70
Storage Temperature (°C) -30 ~ +80



Manufacturer ISO Certification

ISO certification Tailor Pixels






Quality Verification Processes


2 Types of Microscopy-Inspections
  • In process of Backlight assembly and FOG bounding
3 Stages of Aging-Tests
  • Sampling from FOG line, testing in normal and high-temperature environment
  • Sampling from Finished Product: testing in high-temperature enviroment
4 Types of Lab Tests
  • High-Temperature High-Humidity Resistance Test
  • Thermal Shock Test
  • Vibration Test
  • Drop test
5 Times of Quality Inspections
  • Materials in-coming inspection
  • Online inspection
  • Final inspection before packing
  • IQC inspection before stock
  • OQC inspection before loading

Additional information

Input Interface / Signal


HDMI Controller Board
